SR	G	-03	C
Series number	Type of  connection	Valve size	With check valve
SR	G:sub plate  type T:Thread type	03：3/8" 06：3/4" 10：11/4"	C:With -:Without

Model		Rated flow ℓ/min	Max.operating pressure mpa	Weight kg
Sub plate  type	Thread type
SRT-03	SRG-03	30	25	1.4	1.5
SRCT-03	SRCG-03	30	25	1.5	1.5
SRT-06	SRG-06	80	25	2.6	2.7
SRCT-06	SRCG-06	80	25	3.5	4.4
SRT-10	SRG-10	200	25	6.1	5.2
SRCT-10	SRCG-10	200	25	7.4	8.1

1、Recommended Viscosity: Viscosity recommended by the normal working hours: 15 ~ 400cst.
2、Recommended oil: oil-based hydraulic oil: equivalent to ISO VG32 or VG46 use of oil, the use of other types of hydraulic oil, please contact our Technology Department.
3、Working oil temperature: continuous working temperature of 5 ~ 70 ℃.
4、Pollution Control: It should pay attention to controlling the pollution of hydraulic oil, otherwise it will cause damage or shorten the life of the valve. Please ensure that pollution degree NAS11-class, with 25μor more sophisticated pipeline oil filter.
5、Flow Control: Regulating traffic, relax locking nut, and slowly turning the handle to adjust flow rate,, SRCG (T) series of clockwise as the flow increase, counterclockwise to decrease in the flow adjustment is completed, do not forget you have a tight screw locking nut, SRG (T) series and vice versa.
