BS	G	-06	H	-2B2	-A2	5	-D5	-2P
Series number	Type of connection	Valve size	Pressure adj.  Range	Type of  connection	Solenoid type	HZ	Terminal	Multi-pressure control
BS、BHS、SBS	G:sub plate  type T:Thread type	03 06 10	B：1-7 C：3.5-14 H：7-25	For optional venting conditions as below	A1:ac110v D1:dc12v A2:ac220v D2:dc24v A3:ac380v	5：50HZ 6：60HZ	D4:jis d5:din	None:single pressure control 2p:duopressure control 3p:tripressure control

Model		Rated flow ℓ/min	Max.operating pressure mpa	Pressure adj.  Range mpa	Weight kg
Sub plate  type	Thread type				Sub plate  type	Thread type
BSG-03	BST-03	100	25	B：1-7 C：3.5-14 H：7-25	7.1	6.5
BSG-06	BST-06	200	25		8.0	7.4
BSG-10	BST-10	400	25		11.3	11.1
BSG-03-2P	-	100	25		10.0	-
BSG-03-3P	-	100	25		10.0	-
BSG-06-2P	BST-06-2P	200	25		11.0	9.0
BSG-06-3P	BST-06-3P	200	25		11.0	9.0
SBSG-03	-	100	25		6.3	-
SBSG-06	-	200	25		7.2	-
SBSG-03-2P	-	100	25		10.8	-
SBSG-06-2P	-	200	25		11.7	-

1、When doing a normal move recommended by the viscosity :15-400cSt.
2、Listed below can be used any kind of hydraulic oil. Using the equivalent of ISOVG32 or VG46 hydraulic actuation fluid.
3、Continuous working temperature of 5-70 ℃.
4、Should be noted that control of hydraulic fluid contamination, otherwise it will cause damage or shorten the life of the valve. Please ensure that pollution of NAS 1638-11 level, with 25μ or more sophisticated pipeline oil filter.
5、Back to the oil port back-pressure can not exceed 0.5MPa.
6、Back to the pipeline should be made directly back to tank, non-return valves and other pipe connections.
7、Adjust the voltage by the handle, the step-up to be a clockwise direction to adjust slowly, step-down is in the opposite direction, pressure regulator must be locked after a fixed nut.
8、Small flow tends to set the pressure instability, 03,06 specifications use the 8 ℓ/min flow rate of more than 10 specifications use the 15 ℓ/min or more traffic.
