RC	B	G	-03
Series number	Pressure adj.  Range	Type of  connection	Valve size
R:reducing rc:reducing added to designated integral check	B:10-70kgf/cm2 C:35-140kgf/cm2 H:70-250kgf/cm2	G:sub plate  type T:Thread type	03：10（3/8"） 06：25（3/4"） 10：32（11/4"）

Model		Rated flow ℓ/min	Max.operating pressure mpa	Pressure adj.  Range mpa	Drain ℓ/min	Weight kg
Sub plate  type	Thread type					Sub plate  type	Thread type
RG-03	RT-03	50	25	B：0.5-7 C：3.5~14 H：7-25	0.8	4.5	4.3
RCG-03	RCT-03	50	25		0.8	5.4	4.8
RG-06	RT-06	125	25		1	6.8	6.9
RCG-06	RCT-06	125	25		1	8.1	7.8
RG-10	RT-10	250	25		1.2	11.0	12.0
RCG-10	RCT-10	250	25		1.2	13.8	13.8

1、Amount of leakage around the pressure 20.5MPa when measured.
2、RCG, RCT is equipped with one-way valve allows for the implementation of components A, B two holes, while the RG, RT can only be applied to the P loop holes.
3、Adjust the voltage by the handle, the step-up to be a clockwise direction to adjust slowly, step-down is in the opposite direction, pressure regulator must be locked after a fixed nut.
4、Oil spills must be a port close to the low atmospheric pressure, under the direct pass back pressure tank.
